Mini HIL Product Description

Mini HIL is a compact and high-performance Hardware-in-the-Loop testing solution that enables fast and reliable ECU and embedded-system validation. It is designed for real-world testing, repeatable automation, and high-confidence product releases.

Mini HIL Board

1. I/O & Hardware Interface

  • 4x Relay Outputs (for load/control switching)
  • 2x DC Relay Channels (high-current applications)
  • 4x Configurable GPIOs (wide voltage range support)
  • Robust and flexible interface for real-world ECU testing

2. Communication Interfaces

  • CAN interface
  • LIN Interface (automotive network simulation & testing)
  • UART / SPI / I2C Support
  • Enables seamless integration with sensors, ECUs, and peripherals

3. Analog & Signal Simulation

  • 2x ADC Inputs (accurate signal measurement)
  • 2x DAC Outputs (sensor signal simulation)
  • Supports real-time analog signal injection and monitoring

4. Automation & Control

  • Scripting-Based Test Automation
  • Custom test sequence execution
  • Ideal for validation, regression, and repeatable testing

5. EOL (End-of-Line) Testing

  • Designed for production line validation
  • Fast pass/fail decision making
  • Improves product quality and reduces testing time

6. Data Logging & Monitoring

  • Real-time data logging
  • Capture and analyze test results
  • Useful for debugging and traceability

7. Built-in Test Instruments

  • Functional Signal Generator
  • Basic Oscilloscope Capability
  • Reduces need for external lab equipment
